What do the Suffix Letters in KUKA Robot Models Mean?
Release time:
2025-06-25 17:21
Source:
What do the Suffix Letters in KUKA Robot Models Mean?
Hello Friends in the robot industry, do you often involve the problem of robot selection? So do you know what the robot model means? What does the suffix of the robot model represent?
Based on more than ten years of experience in the robot industry, we will first sort out the model explanation of KUKA robots and share them with friends.
Today, let's talk about the suffix letters of the robot model
First of all, it is necessary to know the meaning of the KUKA robot model, such as:
KR 210 R 2700 - 2 C
KR: Kuka Robot
210: Maximum load
R 2700: Working radius
-2：The second generation of the QUANTEC series
C：Inverted
Here C is the suffix, **C**: Ceiling
What other suffixes have you seen besides C? extra，ultra，titan
In fact, some of the suffixes are just names, and they don't specifically point to any purpose or process, such as ultra, this name is not very familiar, at least recently you should have heard of it.
Titan, did you think of the Titanic?
These are actually a name for the robot, and there is not much about the process or installation method.
But the suffixes are not only these, I have listed some below, which are not comprehensive, but most of them should be there.
**Arctic**: Used for temperature ranges below 0 °C (273 K).
**C**: Ceiling
**CR**: Clean Room
**EX**: Ex areas
**F**: Foundry
**F exclusive** : Foundry exclusive
**HA**: High precision
**HI**: High Inertia
**HM**: Hygienic Machine (Used in the main and sideline food industry)
**HC**: Health Care (Identification of KUKA products used in the medical field.)
**HP**: High protection
**HO**: Hygienic Oil (Used in the non-staple food industry)
**HP**: High Protection
**HW**: Hollow Wrist
**K**: Rack-mounted (High Platform)
**KS**: Low-profile rack-mounted
**MT**: Machine Tooling
**P**: Stamping in-line robots
**PA**: Palletizing robots
**SC**: Special Connection
**W**: Wall
**WP**: Waterproof
